Walterscheid - WWZ25801210IOG - 1/2 CARDAN WIDE ANGLE 36 INT S4 WITHOUT JAW

OEM Supplier

SKU: walterscheid-wwz25801210iog

Walterscheid - WWZ25801210IOG - 1/2 CARDAN WIDE ANGLE 36 INT S4 WITHOUT JAW

1109,92 €909,77 € (IVA esclusa)

Disponibile - pronto per la spedizione

Spedizione entro 96 ore
Spedizione gratuita

Paga in sicurezza con

Prezzo

1109,92 €

Half PTO shaft with guard Declaration of conformity User instructions Supplied without yoke and cross piece Lubricating interval of 8 hours Meets the requirements according to EC 89/392 EEC Meets safety standard EN12965 Provided with "CE" marking Angle in continuous use maximum 25º Angle may be 80º only briefly Max. dyn. power 540 rpm: 66kW - 1175Nm Max. dyn. power 1000 rpm: 102kW - 975Nm Values at bending angle 10° and service life 1000 hours
Walterscheid
Walterscheid is a leading manufacturer of driveline components and power transmission systems for agricultural machinery. The brand produces PTO shafts, couplings, and gearboxes for tractors and implements. Its solutions are engineered for high torque and durability in demanding farming applications. Shop more than 5,365 genuine Walterscheid spare parts.

Marca
Walterscheid
Part Numbers
wwz25801210iog
Unit
Each
Length
1014 mm
Includes
Half PTO shaft with guard Declaration of conformity User instructions Supplied without yoke and cross piece
Size code
WW 2580
Properties
Lubrication interval: 8 hours Fulfilling the requirements laid out in EC 89/392 EEC Compliant with EN12965 safety standard CE marking available
Consists of
PTO half shaft with shielding Declaration of conformity Instruction manual Supplied without yoke and joint cross
Technical info
Working angle with continuous use maximum 25º Working angle may only briefly be 80º Max. dynamic capacity 540 rpm: 66 kW, 1175 Nm Max. dynamic capacity 1000 rpm: 102 kW, 975 Nm Values at working angle 10° and service life 1000 hours
Product details
Half PTO shaft with guard Declaration of conformity User instructions Supplied without yoke and cross piece Lubricating interval of 8 hours Meets the requirements according to EC 89/392 EEC Meets safety standard EN12965 Provided with "CE" marking Angle in continuous use maximum 25º Angle may be 80º only briefly Max. dyn. power 540 rpm: 66kW - 1175Nm Max. dyn. power 1000 rpm: 102kW - 975Nm Values at bending angle 10° and service life 1000 hours
Protection type
SD25
Long description
Wide-angle PTO shaft assembly 80° series WW 2580 / 80° (male) suitable for wide spreader, fertiliser machine, big baler and silage wagon etc.
Application range
Broad spreader Slurry wagon Big baler Silage wagon
Inner tube profile
S4GA
Locking type by tractor side
Wide angle without UJ
Cross joint length by machine side
89 mm
Cross joint length by tractor side
89 mm
Cross joint bush diameter by machine side
36 mm
Cross joint bush diameter by tractor side
36 mm
Cross joint length by machine side - longer part
106 mm
Cross joint length by tractor side - longer part
106 mm
Cross joint bush diameter by machine side - longer part
32 mm
Cross joint bush diameter by tractor side - longer part
32 mm
