ARAG - 471202 - Manual main valve 20BAR/ 180L ARAG

OEM Quality

SKU: arag-471202

ARAG - 471202 - Manual main valve 20BAR/ 180L ARAG

126,15 €103,40 € (IVA esclusa)

Disponibile - pronto per la spedizione

Spedizione entro 96 ore
Spedizione gratuita

Paga in sicurezza con

Prezzo

126,15 €

Arag
Arag produce sistemi di lubrificazione e gestione dei fluidi per macchinari agricoli. Il marchio produce pompe per olio, filtri e sistemi di raffreddamento per trattori e mietitrebbie. Le sue soluzioni aumentano la durata e l'efficienza degli impianti nelle operazioni agricole. Scopri oltre 422 ricambi originali Arag.

Marca
Arag
Part Numbers
471202
Unit
Each
Flow max.
150 l/min
Properties
Housing made from fibreglass-reinforced nylon Inner parts made from Delrin® and Inox steel AISI 303 Viton® seals Are equipped with hose nipples for the process. Further connections can be found under "easylink" P217817
Consists of
Composed of manually operated main switch valve with adjustable maximum-pressure valve
Hose connection
IN: 25mm; BY-PASS: 30mm mm
Application range
Main switch valve: controls the opening/closing of the main control valve and consequently the discharging of the liquid via the system. (Open valve: the liquid is delivered to the operating circuit; closed valve: the liquid is delivered to the tank) Pressure relief valve: Releases the available liquid surplus when the programmed maximum pressure is reached. The valve can be adjusted manually Suitable for screwed fittings When using fittings in modular form, use an adapter (463/ T5)
Working pressure max.
20 BAR
EAN
8026834142107
